HOQS N123 Neo 12" Mid Frequency Driver
AU$330.00
Instock x 4
was AU$345.00 Save 4%
Neo Motor, 3" VC, Optimised for Paraflex Kick-Tops
Estimated delivery time
Pickup: today, 11:00 AM–07:00 PM
In stock: 4 available
1
Save this product for later
HOQS N123 Neo 12" Mid Frequency Driver
Product Details
HOQS 12" Mid Frequency driver, Neo Motor, optimised for Paraflex Kick-Tops.
OFC coil with Glass Fiber former
Inside-outside wound 3" diameter 2-layer voice coil
Low inductance neo motor with abundant force for its class.
High compliance suspension combined with light moving mass and previously mentioned strong motor.
Ventilation offered on the Top Plate, coil former, and Back Plate Periphery.
Heavy duty cast aluminium frame.
Weatherproof cone treatment (front)
Power handling 'Nominal': 500W
Power handling 'Program': 1000W
Overall Diameter: 320mm
Bolt Circle Diameter: 300mm
Bolt Hole Diameter: 6.5mm
Baffle Cutout Diameter: 281mm
Overall Depth: 143mm
Flange & Gasket thickness: 16mm
Single Shipping Weight 5.5kg
Single Package Size: 35x35x20 cm
Can ship in cartons of 2 units (2 drivers)
Carton Shipping Weight: 11.7kg
Carton Shipping Size: 37x37x41.5 cm
Thiele/Small parameters
| Sd | 532.36 cm2 |
| Re | 5.80 ohms |
| fs | 37 Hz |
| Vas | 96.99 litres |
| Qes | 0.16 |
| Qms | 17.07 |
| Qts | 0.16 |
| n0 | 3.40% |
| Le @ 1kHz | 0.79 mH |
| Pmax | 1000 Watts |
| Xmax | 6.3 mm |
| BL | 25.49 |
| Mms | 70.02 g |
| EBP | 231.25 |
| SPL Sens 1w@1m | 98.65 dB |
Specifications
